Blue Sea 285-Series Circuit Breaker - Surface mount

$119.00
Tax included.
Amp: 25A

285-Series Circuit Breaker

Thermal circuit breakers provides medium duty circuit protection for 25 to 150

Amp loads when switching and circuit protection are both required.

  • Drop in replacement for 185-Series Circuit Breakers
  • Visible reset lever shows open condition
  • Ignition protected - Safe for installation aboard gasoline powered boats
  • Meets SAE J1171 external ignition protection requirements
  • Weather Resistant
  • Combines switching and circuit breaker function into one unit*
  • "Trip Free" - cannot be held closed after trip

    * Do not use as a switch where high inrush currents are expected.

    Specifications

  • Amperage - 25A-150A Please select below
  • Maximum Voltage - 48V DC
  • Mounting - Surface mount
  • Circuit Breaker Type - Thermally responsive Bi-metal blade
  • Interrupt Capacity (The fault current that a device, normally a fuse or circuit breaker is capable of breaking without damage) - 3000A @ 48V Achieved using SAE J1625
  • Minimum Operating Temperature - 85° C
  • Maximum Operating Temperature - -40° C
  • Circuit Breaker Class - Type III - switchable/manual reset - trip free
  • Terminal Stud - M6 (accepts 1/4" Ring Terminal)
  • Terminal Stud Torque - 50 in-lb (5.65 Nm)
  • Weight - 0.50lb (0.23 kg)

    • Amp: 25A
